COM
Remote Capable Combination Exit Sign Emergency Light
Remote Capable Combo Exit Sign

COM-PH

Rectangle Heads

Remote Capable Emergency Light Exit Sign

COM

Round Heads

lifetime-warranty
Made in USA
UL 924 Listed

Dimensions

HOUSING

Height: 13.3″
Width: 12.3″
Depth: 2.3″
(Add 12.5″ to the Overall Width Dimension for Round-Head Models)

Series Features

  • 120/277 VAC Operation
  • 1.5 Hours of Emergency Illumination
  • Integrated Solid State System
  • Constant Current, Controlled, Automatic Charger Circuit
  • Low-Voltage Battery Cutoff
  • Brownout Sensitivity
  • Maximum Input Rating (120 or 277VAC) – 2.5 Watts

EMERGENCY LIGHT

  • (2) 6VDC, 4-Watt HIT Lamps (PH) (Total 8 Watts)
  • (2) 6VDC, 4-Watt PAR-36 HIT Lamps (Total 8 Watts)



EMERGENCY EXIT

  • LED (Indirect)
    (1) Strip, 120/277 VAC, 2.5-Watt
    (2) Strips, (-DS), 120/277 VAC, 3.5-Watt



  • Light-Emitting Diodes – 25+ Year Life
  • Illuminates with Uniform Color and Brightness
  • Indirect Placement for Diffused Legend Output
  • Increased LED Brightness Level in Emergency Mode



  • Sealed Lead Calcium Battery
  • 6-Volt Operation (S65)
  • Maintenance-Free
  • Ceiling, End or Back Mount
  • Canopy
  • Universal Stencil
  • Directional Chevron Snapouts
  • 20-Gauge Steel Housing
  • Polycarbonate Lamp Enclosures (-PH)
  • White Powder-Coat Finish
  • Easy Installation
  • Amber (Power On) Indicator
  • Test Switch
  • UL Listed

Options - Add Suffix to Catalog Number

-SuffixOption Description
-DSDouble LED Strip
-HIHigh-Intensity LEDs
-UUniversal Face (Additional Backplate – Double-Face Signs Only.)

Ordering Information

2

COM

1
R
W
W
-PH
-QC

Emergency Light

0
1
2

Series

COM

# of Faces

1
2

Letter Color

R – Red
G
– Green
W– White

Stencil Color

W – White
B
– Black
PM– Painted Matte Chrome

Housing Color

W – White
B
– Black
PM– Painted Matte Chrome

Head Type

Blank – Rnd.
PH – Plastic Head

Options

Factory Options
